Finisar - Finisar FTLF1436P3BCL
SFP28 transceiver module - 25GbE - 25GBase-LR - LC single-mode - up to 6.2 miles - 1310 nm
Finisar
FTLF1436P3BCL
N/A
N/A
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Finisar FTLF1436P3BCL - SFP28 transceiver module - 25GbE |
| Device Type | SFP28 transceiver module - LC single-mode |
| Form Factor | Plug-in module |
| Cabling Type | 25GBase-LR |
| Data Transfer Rate | 25.78 Gbps |
| Optical Wave Length | 1310 nm |
| Data Link Protocol | 25GbE |
| Max Transfer Distance | 6.2 miles |
| Dimensions (WxDxH) | 0.6 in x 2.2 in x 0.5 in |
| General | |
| Device Type | SFP28 transceiver module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 25GBase-LR - LC single-mode female x 2 |
| Miscellaneous | |
| Compliant Standards | Laser Class 1, EN 60825, IEC 60825, MSA SFF-8472, MSA SFF-8431, MSA SFF-8432, RoHS 2011/65/EU |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 25GBase-LR |
| Data Link Protocol | 25GbE |
| Data Transfer Rate | 25.78 Gbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 6.2 miles |
| Features | Hot swap module replacement, Digital Diagnostics |
| Compliant Standards | IEEE 802.3cc |
| Power | |
| Power Consumption Operational | 1.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Dimensions & Weight | |
| Width | 0.6 in |
| Depth | 2.2 in |
| Height | 0.5 in |
