APC - APC Smart-UPS SRT 1000VA
UPS (rack-mountable / external) - AC 120 V - 900 Watt - 1000 VA - RS-232, USB - output connectors: 6 - PFC - 2U - black
APC
SRT1000XLA
N/A
0731304329985
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | APC Smart-UPS SRT 1000VA - UPS - 900 Watt - 1000 VA |
| Device Type | UPS - Power Factor Correction (PFC) - rack-mountable / external |
| Rack Size | 2U |
| Weight | 48.5 lbs |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V ± 2% |
| Power Capacity | 900 Watt / 1000 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 6 x power NEMA 5-15R |
| Battery | Lead acid |
| Run Time (Up To) | 10 min at full load |
| Networking | RS-232, USB |
| Color | Black |
| Dimensions (WxDxH) | 3.3 in x 20 in x 17 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - Power Factor Correction (PFC) - rack-mountable / external |
| Height (Rack Units) | 2U |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x management (RS-232) - RJ-45 ¦ 1 x EPO (emergency power off) ¦ 1 x management (USB) |
| Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years |
| Miscellaneous | |
| Cables Included | Power cable 6 ft ¦ USB cable - external |
| Features | LCD display, Eco-Mode, hot-swappable batteries, LED indicators, lightning protection, cold-start function, firmware upgradable, automatic self-test, audible alarm, internal bypass |
| Compliant Standards | CSA C22.2 No. 107.3, FCC Part 15 A, UL 1778, IP20 |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Sound Emission | 50 dBA |
| Battery | |
| Technology | Lead acid |
| Run Time (Up To) | 10 min at full load ¦ 25 min at half load |
| Recharge Time | 3 hours |
| Features | Maintenance free, sealed, leak-proof |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 80 - 150 V |
| Frequency Provided | 50/60 Hz ± 3Hz |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 6 x power NEMA 5-15R |
| Output Voltage | AC 120 V ± 2% - 50/60 Hz |
| Power Capacity | 900 Watt / 1000 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 432 Joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 83.1% at 25% Load, 90.7% at 100% Load, 88.6% at 50% Load, 90.2% at 75% Load |
| Dimensions & Weight | |
| Width | 3.3 in |
| Depth | 20 in |
| Height | 17 in |
| Weight | 48.5 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23.4 in |
| Shipping Depth | 29.5 in |
| Shipping Height | 9.7 in |
| Shipping Weight | 65.26 lbs |
| Sustainability Information | |
| ENERGY STAR | Yes |
