StarTech.com - StarTech.com MSA Uncoded Compatible SFP Module, 1000BASE-SX, 1GbE Multi Mode (MMF) Fiber Optic Transceiver, 1GE Gigabit Ethernet SFP, LC Connector, 550m, 850nm, DDM, 1Gbps Mini GBIC Module
Lifetime Warranty (SFP1000SXST) - SFP (mini-GBIC) transceiver module - 1GbE - 1000Base-SX - LC multi-mode - up to 1800 ft - 850 nm - for P/N: US1GA30SFP, US1GC30SFP
StarTech.com
SFP1000SXST
N/A
0065030873352
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | StarTech.com MSA Uncoded Compatible SFP Module, 1000BASE-SX, 1GbE Multi Mode (MMF) Fiber Optic Transceiver, 1GE Gigabit Ethernet SFP, LC Connector, 550m, 850nm, DDM, 1Gbps Mini GBIC Module - Lifetime Warranty (SFP1000SXST) - SFP (mini-GBIC) transceiver module - 1GbE |
| Device Type | SFP (mini-GBIC) transceiver module - LC multi-mode |
| Form Factor | Plug-in module |
| Cabling Type | 1000Base-SX |
| Data Transfer Rate | 1.25 Gbps |
| Optical Wave Length | 850 nm |
| Data Link Protocol | 1GbE |
| Max Transfer Distance | 1800 ft |
| Dimensions (WxDxH) | 0.5 in x 2.3 in x 0.5 in |
| Weight | 1.06 oz |
| Manufacturer Warranty | Limited lifetime warranty |
| Designed For | P/N: US1GA30SFP, US1GC30SFP |
| General | |
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Color | Silver |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-SX - LC multi-mode x 2 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS, MSA, RCM, WEEE |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-SX |
| Data Link Protocol | 1GbE |
| Data Transfer Rate | 1.25 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 1800 ft |
| Features | Digital Diagnostics Monitoring (DDM), full duplex mode, Digital Optical Monitoring (DOM) support |
| Compliant Standards | IEEE 802.3z |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 - 95% |
| Dimensions & Weight | |
| Width | 0.5 in |
| Depth | 2.3 in |
| Height | 0.5 in |
| Weight | 1.06 oz |
| Compatibility Information | |
| Designed For | P/N: US1GA30SFP, US1GC30SFP |
