CyberPower - CyberPower Monitored Series PDU31106
Power distribution unit (rack-mountable) - AC 200-240 V - Ethernet, serial - input: NEMA L6-30P - output connectors: 42 (6 x IEC 60320 C19, 36 x IEC 60320 C13) - 0U - 10 ft cord
CyberPower
PDU31106
N/A
0649532620395
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | CyberPower Monitored Series PDU31106 - power distribution unit |
| Device Type | Power distribution unit - rack-mountable |
| Cord Length | 10 ft |
| Rack Size | 0U |
| Weight | 12.35 lbs |
| Input Voltage | AC 200-240 V |
| Output Voltage | AC 200-240 V |
| Input Connectors | 1 x power NEMA L6-30P |
| Output connectors | 36 x power IEC 60320 C13 ¦ 8 x power IEC 60320 C19 |
| Networking | Ethernet, serial |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI, SMTP, NTP |
| Included Accessories | Cable retention tray, 6 M3x6 mounting screws, 6 M5x12 mounting screws, 6 M4x5 mounting screws, 63 cable ties |
| Dimensions (WxDxH) | 2.2 in x 1.9 in x 65.4 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Power distribution unit - rack-mountable |
| Height (Rack Units) | 0U |
| Cord Length | 10 ft |
| Expansion / Connectivity | |
| Interfaces | Management (Ethernet) - RJ-45 ¦ Serial - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Miscellaneous | |
| Included Accessories | Cable retention tray, 6 M3x6 mounting screws, 6 M5x12 mounting screws, 6 M4x5 mounting screws, 63 cable ties |
| Cables Included | Power cable 10 ft ¦ Serial cable - external |
| Rack Mounting Kit | Included |
| Features | LCD display, voltage monitoring, current meter, overload protection, email alerts support, firmware upgradable, SMS notification, power measuring |
| Compliant Standards | FCC Class A certified, RoHS, UL 60950-1 |
| Networking | |
| Remote Management Interface | Ethernet, serial |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI, SMTP, NTP |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Power Device | |
| Input Voltage | AC 200-240 V |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA L6-30P |
| Power Output Connectors Details | 36 x power IEC 60320 C13 ¦ 8 x power IEC 60320 C19 |
| Output Voltage | AC 200-240 V |
| Max Electric Current | 20 A |
| Dimensions & Weight | |
| Width | 2.2 in |
| Depth | 1.9 in |
| Height | 65.4 in |
| Weight | 12.35 lbs |
