CyberPower - CyberPower Smart App Online OL1000RTXL2UN
UPS (rack-mountable / external) - AC 100-125 V - 900 Watt - 1000 VA - 9 Ah - RS-232, USB - output connectors: 8 - 2U - black
CyberPower
OL1000RTXL2UN
N/A
20649532621914
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | CyberPower Smart App Online OL1000RTXL2UN - UPS - 900 Watt - 1000 VA |
| Device Type | UPS - rack-mountable / external |
| Rack Size | 2U |
| Weight | 39.59 lbs |
| Input Voltage | AC 100-125 V |
| Output Voltage | AC 100/110/115/120/125 V ± 2% |
| Power Capacity | 900 Watt / 1000 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 8 x power NEMA 5-15R |
| Battery | Lead acid - 9 Ah |
| Batteries Qty | 3 |
| Run Time (Up To) | 7.4 min at full load |
| Networking | RS-232, USB |
| Remote Management Protocol | CLI, Web NMS |
| Color | Black |
| Dimensions (WxDxH) | 17 in x 16.9 in x 3.5 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x management (RS-232) ¦ 1 x management (USB) ¦ 1 x EPO (emergency power off) |
| Expansion Slots | 1 (total) / 0 (free) x expansion slot |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | Power cable 10 ft ¦ USB cable - external ¦ Serial cable - external ¦ Phone cable - external |
| Rack Mounting Kit | Included |
| Equipment Protection Value | 400000 US Dollars |
| Features | Audible alarm, LCD display, GreenPower UPS Technology, overload protection, cold-start function, firmware upgradable, hot-swappable batteries, Eco-Mode, generator compatible, rotatable LCD panel, double conversion, Fast Charge technology |
| Compliant Standards | FCC Part 15 B, RoHS, UL 1778 5th edition, CSA C22.2 No.107.3-05, IEC 61000-4-5 Level 3 |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Remote Management Protocol | CLI, Web NMS |
| Software / System Requirements | |
| Software Included | PowerPanel Business Edition |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Sound Emission | 55 dBA |
| Battery | |
| Quantity | 3 |
| Technology | Lead acid |
| Voltage Provided | 12 V |
| Capacity | 9 Ah |
| Run Time (Up To) | 7.4 min at full load ¦ 20 min at half load |
| Recharge Time | 4 hours |
| Transfer Time | 0 ms |
| Features | Sealed |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 100-125 V |
| Input Voltage Range | AC 60 - 150 V |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 8 x power NEMA 5-15R |
| Output Voltage | AC 100/110/115/120/125 V ± 2% - 50/60 Hz |
| Power Capacity | 900 Watt / 1000 VA |
| Dataline Surge Protection | Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 1780 Joules |
| Circuit Protection | Circuit breaker |
| Efficiency | 94% Eco mode |
| Power Factor (PF) | 0.99 |
| Dimensions & Weight | |
| Width | 17 in |
| Depth | 16.9 in |
| Height | 3.5 in |
| Weight | 39.59 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 9.3 in |
| Shipping Depth | 21.5 in |
| Shipping Height | 22.5 in |
| Shipping Weight | 53.51 lbs |
| Environmental Standards | |
| ENERGY STAR | Yes |
