StarTech.com - StarTech.com 4-port PCI Express RS232 Serial Adapter Card, PCIe RS232 Serial Host Controller Card, PCIe to Serial DB9, 16950 UART, Low Profile Desktop Expansion Card, Windows, macOS, Linux
Full/Low-Profile (PEX4S953LP) - Serial adapter - PCIe low profile - RS-232 x 4
StarTech.com
PEX4S953LP
N/A
0065030887052
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | StarTech.com 4-port PCI Express RS232 Serial Adapter Card, PCIe RS232 Serial Host Controller Card, PCIe to Serial DB9, 16950 UART, Low Profile Desktop Expansion Card, Windows, macOS, Linux - Full/Low-Profile (PEX4S953LP) - serial adapter - PCIe - RS-232 x 4 |
| Device Type | Serial adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express x1 |
| PCI Specification Revision | PCIe 1.1 |
| Ports | RS-232 x 4 |
| Dimensions (WxDxH) | 2.5 in |
| Data Link Protocol | RS-232 |
| Data Transfer Rate | 921.6 Kbps |
| Processor | ASIX AX99100 |
| System Requirements | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Linux 2.4.x - 2.6.x LTS versions only |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Serial adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express x1 |
| PCI Specification Revision | PCIe 1.1 |
| Expansion / Connectivity | |
| Interfaces | 4 x RS-232 - 9 pin D-Sub (DB-9) (on cable) ¦ 1 x SATA power - 15 pin Serial ATA power (internal) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Included Accessories | Full-height bracket |
| Compliant Standards | FCC, RoHS, WEEE, REACH |
| Networking | |
| Ports | RS-232 x 4 |
| Connectivity Technology | Wired |
| Data Link Protocol | RS-232 |
| Data Transfer Rate | 921.6 Kbps |
| Features | Full duplex mode, 256-byte FIFO |
| Software / System Requirements | |
| OS Required | Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Linux 2.4.x - 2.6.x LTS versions only |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 176 °F |
| Humidity Range Operating | 5 - 85% |
| Processor / Memory | |
| Processor | ASIX AX99100 |
| Dimensions & Weight | |
| Depth | 2.5 in |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 8.4 in |
| Shipping Depth | 5.9 in |
| Shipping Height | 2 in |
| Shipping Weight | 13.61 oz |
