NVIDIA - NVIDIA ConnectX-6 Dx MCX623106AN-CDAT
Network adapter - PCIe 4.0 x16 - 100 Gigabit QSFP56 x 2
NVIDIA
MCX623106AN-CDAT
N/A
7290108485226
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | NVIDIA ConnectX-6 Dx MCX623106AN-CDAT - network adapter - PCIe 4.0 x16 - 100 Gigabit QSFP56 x 2 |
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 4.0 x16 |
| PCI Specification Revision | PCIe 1.1, PCIe 2.0, PCIe 3.0, PCIe 4.0 |
| Ports | 100 Gigabit QSFP56 x 2 |
| Data Link Protocol | 10GbE, 40GbE, 100GbE, 25GbE, 50GbE |
| Data Transfer Rate | 100 Gbps |
| Network / Transport Protocol | TCP/IP, UDP/IP, IPSec, SMB |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qbg, IEEE 1588v2, IEEE 802.3bj, IEEE 802.3by, IEEE 802.3cd |
| General | |
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express 4.0 x16 |
| PCI Specification Revision | PCIe 1.1, PCIe 2.0, PCIe 3.0, PCIe 4.0 |
| Expansion / Connectivity | |
| Interfaces | 2 x 100Gb Ethernet - QSFP56 |
| Miscellaneous | |
| Encryption Algorithm | TLS, 256-bit AES-GCM, 128-bit AES-GCM, AES-XTS |
| Networking | |
| Ports | 100 Gigabit QSFP56 x 2 |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet, 40 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 50 Gigabit Ethernet |
| Data Transfer Rate | 100 Gbps |
| Network / Transport Protocol | TCP/IP, UDP/IP, IPSec, SMB |
| Features | Firewall protection, MPLS support, DoS attack prevention, firmware upgradable, QoS, PXE support, LSO, LRO, RSS, UEFI support, SR-IOV, Energy Efficient Ethernet, AER, checksum offload support, MSI-X, iSCSI remote boot, Ethernet remote boot, TSS, RoCE, NC-SI, VXLAN, NVGRE, Link Aggregation, TPH, SDN, MSI, DPDK, iSCSI Extensions over RDMA (iSER), VLAN Tagging, ASAP, MCTP over SMBus, NFV, GENEVE support, NVMe-oF |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3ba, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qbg, IEEE 1588v2, IEEE 802.3bj, IEEE 802.3by, IEEE 802.3cd |
