Vertiv - Cybex SCM145DPH
KVM / audio / USB switch - 4 x KVM / audio / USB - 1 local user - desktop - TAA Compliant
Vertiv
SCM145DPH-400
N/A
0636430089669
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Cybex SCM145DPH - KVM / audio / USB switch - 4 ports - TAA Compliant |
| Device Type | KVM / audio / USB switch - 4 ports |
| Subtype | KVM |
| Ports | 4 x KVM / audio / USB |
| KVM Users Qty | 1 local user |
| Features | NIAP Protection Profile 4.0, CAC reader support, touch screen support, dual view, Dedicated Peripheral Port |
| Power | AC 100-240 V 2.5 A |
| Dimensions (WxDxH) | 13.7 in x 5 in x 1.7 in |
| Weight | 3.31 lbs |
| TAA Compliant | Yes |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | KVM / audio / USB switch - 4 ports |
| Enclosure Type | Desktop |
| Subtype | KVM |
| Ports | 4 x KVM / audio / USB |
| KVM Local Users Qty | 1 local user |
| Keyboard / Mouse Interface | USB |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Features | NIAP Protection Profile 4.0, CAC reader support, touch screen support, dual view, Dedicated Peripheral Port |
| Expansion / Connectivity | |
| Interfaces | 4 x DisplayPort/HDMI input ¦ 4 x USB 2.0 Type B ¦ 4 x keyboard (USB) / mouse (USB) Type B ¦ 4 x audio / headphones phone stereo 3.5 mm ¦ 2 x DisplayPort/HDMI output ¦ 2 x keyboard (USB) / mouse (USB) Type A console ¦ 1 x USB 2.0 Type A console ¦ 1 x headphones output phone stereo 3.5 mm console |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | RCM, FCC Class A certified, VCCI, TUV, NIAP PP 4.0, TUV C |
| TAA Compliant | Yes |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V |
| Electric Current Required | 2.5 A |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 80% RH (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 140 °F |
| Dimensions & Weight | |
| Width | 13.7 in |
| Depth | 5 in |
| Height | 1.7 in |
| Weight | 3.31 lbs |
