Hewlett Packard Enterprise - HPE Networking Instant On AP22
Wireless access point - Bluetooth, Wi-Fi 6 - 2.4 GHz, 5 GHz - DC power - wall / ceiling mountable
Hewlett Packard Enterprise
R6M49A
N/A
0190017480183
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | HPE Networking Instant On AP22 - wireless access point - Bluetooth, Wi-Fi 6 |
| Device Type | Wireless access point |
| Form Factor | Wall / ceiling mountable - indoor |
| Localization | United States |
| Data Link Protocol | Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Concurrent data rate (5 GHz): 1.2 Gbps ¦ Concurrent data rate (2.4 GHz): 574 Mbps |
| Included Accessories | Ceiling rail mount clip |
| Power Over Ethernet (PoE) Supported | PoE |
| Power | DC 12 V |
| Dimensions (WxDxH) | 6.3 in x 6.3 in x 1.5 in |
| Weight | 17.64 oz |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Wireless access point |
| Ruggedized Design | Indoor |
| Width | 6.3 in |
| Depth | 6.3 in |
| Height | 1.5 in |
| Weight | 17.64 oz |
| Localization | United States |
| Expansion / Connectivity | |
| Interfaces | 1 x - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years ¦ Technical support - phone consulting - 90 days ¦ Technical support - web support - 2 years |
| Miscellaneous | |
| Included Accessories | Ceiling rail mount clip |
| Cables Included | 1 x network cable |
| MTBF | 91 years |
| Compliant Standards | UL 2043, EN 60601-1-2, EN 60601-1-1 |
| Networking | |
| Form Factor | Wall / ceiling mountable |
| Connectivity Technology | Wireless |
| Data Link Protocol | Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Concurrent data rate (5 GHz): 1.2 Gbps ¦ Concurrent data rate (2.4 GHz): 574 Mbps |
| Status Indicators | Status |
| Features | Firewall protection, manageable, wall mountable, static IP mode, Trusted Platform Module (TPM), reset button, Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, security lock slot (cable lock sold separately), Advanced Cellular Coexistence (ACC), MU-MIMO technology, PPPoE server, Bluetooth (BLE) clients support, Orthogonal Frequency Division Multiple Access (OFDMA), Target Wait Time (TWT), Smart Mesh technology, BSS Coloring |
| Encryption Algorithm | WPA2, WPA3 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Voltage Required | DC 12 V |
| Power Provided | 18 Watt |
| Software / System Requirements | |
| Software Included | InstantOn |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Antenna | |
| Antenna | Internal |
| Directivity | Omni-directional |
| Gain Level | 3 dBi |
| Internet of Things (IoT) | |
| Communications Technology | Bluetooth Low Energy (LE) |
