Advantech - Advantech IMC-390 series IMC-390-MM-US
Fiber media converter - 1GbE - 10Base-T, 100Base-TX, 1000Base-T - RJ-45 / SC multi-mode - up to 1800 ft - 850 nm
Advantech
IMC-390-MM
N/A
0663069959728
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Advantech IMC-390 series IMC-390-MM-US - fiber media converter - 10Mb LAN, 100Mb LAN, 1GbE |
| Device Type | Fiber media converter - RJ-45 / SC multi-mode |
| Form Factor | Wall / DIN rail mountable |
| Localization | United States |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 850 nm |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Max Transfer Distance | 1800 ft |
| Power Over Ethernet (PoE) | PoE+ |
| Power | AC 120/230 V |
| Dimensions (WxDxH) | 3.6 in x 3.8 in x 0.8 in |
| Weight | 15.87 oz |
| General | |
| Device Type | Fiber media converter |
| Form Factor | Wall / DIN rail mountable |
| Localization | United States |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000 - SC multi-mode female x 2 ¦ 2 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female |
| Miscellaneous | |
| MTBF | 602,720 hours |
| Compliant Standards | FCC Class A certified, CSA, UL, cUL, RoHS |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 1800 ft |
| Features | Auto-negotiation, auto-uplink (auto MDI/MDI-X), Link Fault Pass Through function (LFP), Power Sourcing Equipment (PSE), Jumbo Frames support (up to 10240 bytes) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at |
| Power | |
| Power Over Ethernet (PoE) | PoE+ |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 3.6 in |
| Depth | 3.8 in |
| Height | 0.8 in |
| Weight | 15.87 oz |
