Elo Touch Solutions - Elo I-Series 4.0
Standard - all-in-one - 1 x Snapdragon 660 up to - RAM 4 GB - flash 64 GB - Gigabit Ethernet - 802.11a/b/g/n/ac, Bluetooth 5.0 - Android 10 - monitor: LED 15.6" 1920 x 1080 (Full HD) @ 60 Hz touchscreen - black
Elo Touch Solutions
E390075
N/A
0843173128351
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Elo I-Series 4.0 - Standard - all-in-one Snapdragon 660 - 4 GB - flash 64 GB - LED 15.6" |
| Type | Point of sale terminal - all-in-one |
| Processor | 1 x Qualcomm Snapdragon 660 (8-core) |
| RAM | 4 GB |
| Hard Drive | Flash 64 GB |
| Optical Storage | No optical drive |
| Card Reader | Yes |
| Monitor | 15.6" - LED - 1920 x 1080 (Full HD) @ 60 Hz - 16:9 - touchscreen |
| Camera | Yes |
| Audio Output | Stereo |
| Networking | 1GbE, 802.11a, 802.11b/g/n, Wi-Fi 5, Bluetooth 5.0 |
| Power | (50/60 Hz) |
| OS Provided | Android 10 |
| Software Included | Google Mobile Services |
| Color | Black |
| Dimensions (WxDxH) | 14.9 in x 0.9 in x 9.8 in |
| Weight | 3.97 lbs |
| Manufacturer Warranty | Limited warranty - 2 years |
| General | |
| Type | Point of sale terminal |
| Product Form Factor | All-in-one |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x USB 3.0 (900 mA) ¦ 1 x USB-C ¦ 1 x GPIO ¦ 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 2.0 - micro-USB (support for 1.2 A on one port and 500 mA for the remaining three ports) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Power adapter, screw set |
| VESA Mounting Interface | 75 mm, 100 mm, VESA |
| Compliant Standards | UL, VCCI, cUL, CB, IC, MIC, FCC, RCM |
| RAM | |
| Installed Size | 4 GB |
| Networking | |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0 |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 11 Watt |
| Power Consumption Stand by | 0.4 Watt |
| Power Consumption Sleep | 4.4 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | LED |
| Touchscreen | Yes (10-point multi-touch) |
| Diagonal Size | 15.6" |
| Native Resolution | 1920 x 1080 (Full HD) |
| V-Sync Rate at Max Res. | 60 Hz |
| Widescreen Display | Yes |
| Image Aspect Ratio | 16:9 |
| Horizontal Viewing Angle | +89 / -89 |
| Vertical Viewing Angle | +89 / -89 |
| Response Time | 25 ms |
| Image Brightness | 258 cd/m² |
| Image Contrast Ratio | 700:1 |
| Monitor Features | TouchPro Pro Projected Capacitive (PCAP) technology |
| Audio Output | |
| Sound Output Mode | Stereo |
| Operating System / Software | |
| OS Provided | Android 10 |
| Software | Google Mobile Services |
| Hard Drive | |
| Type | Flash |
| Capacity | 1 x 64 GB |
| Camera | |
| Camera | Yes |
| Resolution (MP) | 8 Megapixel |
| Resolution | 1920 x 1080 |
| Features | Autofocus |
| Audio Input | |
| Type | Two microphones |
| Dimensions & Weight | |
| Width | 14.9 in |
| Depth | 0.9 in |
| Height | 9.8 in |
| Weight | 3.97 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 17.7 in |
| Shipping Depth | 6.5 in |
| Shipping Height | 12.2 in |
| Shipping Weight | 7.72 lbs |
| Card Reader | |
| Type | Card reader |
| Supported Flash Memory Cards | microSD |
| Processor / Chipset | |
| CPU | Qualcomm Snapdragon 660 |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
