HP Inc. - HP Workstation Z2 Mini G5

Wolf Pro Security - mini - 1 x Core i7 10700 / 2.9 GHz - vPro - RAM 16 GB - SSD 512 GB - HP Z Turbo Drive, NVMe, TLC - Quadro P620 - GigE - WLAN: Bluetooth 5.0, 802.11a/b/g/n/ac/ax - Win 10 Pro 64-bit (includes Win 11 Pro License) - monitor: none - keyboard: US - Smart Buy - with HP Wolf Pro Security Edition (1 year)

HP Inc.
643Z0UT#ABA
N/A
0196548064953
N/A
New

Price: $1,210.23

Total Available: 854

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description HP Workstation Z2 Mini G5 - Wolf Pro Security - mini - Core i7 10700 2.9 GHz - vPro - 16 GB - SSD 512 GB - US - with HP Wolf Pro Security Edition (1 year)
Type Workstation - mini
Platform Technology Intel vPro Platform
Localization Language: English / region: United States
Processor 1 x Intel Core i7 (10th Gen) 10700 / 2.9 GHz (4.8 GHz) (8-core)
Processor Socket LGA1200 Socket
Processor Main Features Intel Turbo Boost Technology
Cache Memory 16 MB
Cache Per Processor 16 MB
RAM 16 GB (installed) / 64 GB (max) - DDR4 SDRAM - non-ECC
Storage Controller SATA
Hard Drive SSD 512 GB - PCI Express 3.0 x4 - M.2 2280 - HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Optical Storage No optical drive
Multi-GPU Configuration 1 single GPU card / integrated GPU
Graphics Controller PCIe 3.0 x16 - NVIDIA Quadro P620 / Intel UHD Graphics 630
Video Memory 4 GB GDDR5 SDRAM
Networking GigE, 802.11a, 802.11b/g/n, 802.11ac, Bluetooth 5.0, 802.11ax (Wi-Fi 6)
Keyboard US
Power (50/60 Hz)
OS Provided Windows 10 Pro 64-bit Edition (downgrade from Windows 11 Pro) + Windows 11 Pro License
Dimensions (WxDxH) 8.5 in x 8.5 in x 2.3 in
Weight 4.63 lbs
Manufacturer Selling Program HP Smart Buy
Environmental Standards ENERGY STAR Qualified EPEAT Gold
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site
Bundled with HP Wolf Pro Security Edition (1 year)
General
Platform Technology Intel vPro Platform
Type Workstation
Product Form Factor Mini
Built-in Devices Speaker
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Localization Language: English / region: United States
Bundled with HP Wolf Pro Security Edition (1 year)
Expansion / Connectivity
Slots 1 (total) / 0 (free) x M.2 Card - 2230 (x1 mode) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (x4 mode) ¦ 1 (total) / 0 (free) x MXM (x16 mode)
Interfaces 4 x USB 3.2 Gen 2 (2 rear, 2 side) (one of them is charging) ¦ 1 x headphones/microphone (1 side) ¦ 1 x LAN (Gigabit Ethernet) ¦ 3 x DisplayPort 1.4 ¦ 1 x USB-C 3.2 Gen 2 (1 side) (charging)
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site
Miscellaneous
Theft/Intrusion Protection Security lock slot (cable lock sold separately)
Security Slot Type Kensington security slot
Compliant Standards ACPI, RoHS, WEEE, Common Criteria EAL4+, CECP, low halogen
Manufacturer Selling Program HP Smart Buy
RAM
Installed Size 16 GB / 64 GB (max)
Technology DDR4 SDRAM - non-ECC
Effective Memory Speed 3200 MHz
Rated Memory Speed 3200 MHz
Form Factor SO-DIMM 260-pin
Slots 2 (total) / 1 (empty)
Features Dual channel memory architecture
Configuration Features 1 x 16 GB
Networking
Ethernet Controller Intel I219-LM
Wireless LAN Supported Yes
Wireless NIC Intel Wi-Fi 6 AX 201
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Features Wake on LAN (WoL), PXE support, auto-uplink (auto MDI/MDI-X), dual stream (2x2)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Power
Device Type Power adapter
Voltage Required AC 115/230 V (50/60 Hz)
Power Provided 280 Watt
Efficiency 89%
Environmental Parameters
Min Operating Temperature 41 °F
Max Operating Temperature 95 °F
Humidity Range Operating 10 - 85% (non-condensing)
Storage Controller
Type 1 x SATA
RAID Level RAID 0, RAID 1
Cache Memory
Installed Size 16 MB
Cache Per Processor 16 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Interface Type PCIe 3.0 x16
Multi-GPU Configuration 1 single GPU card / integrated GPU
Graphics Processor NVIDIA Quadro P620 / Intel UHD Graphics 630
Video Memory 4 GB GDDR5 SDRAM
Video Interfaces DisplayPort
Max Monitors Supported 3
Audio Output
Compliant Standards High Definition Audio
Operating System / Software
OS Provided Windows 10 Pro 64-bit Edition (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro License - English
Hard Drive
Type SSD - M.2 2280
Capacity 1 x 512 GB
Interface Type PCI Express 3.0 x4
Features HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Input Device
Type Mouse, keyboard
Dimensions & Weight
Width 8.5 in
Depth 8.5 in
Height 2.3 in
Weight 4.63 lbs
Dimensions & Weight (Shipping)
Shipping Width 6.7 in
Shipping Depth 19.6 in
Shipping Height 11.7 in
Keyboard
Keyboard Name HP 320K
Interface USB
Localization & Layout US
Mouse
Mouse Name HP 320M
Interface USB
Environmental Standards
EPEAT Compliant EPEAT Gold
ENERGY STAR Certified Yes
Processor / Chipset
CPU Intel Core i7 (10th Gen) 10700
Clock Speed 2.9 GHz
Max Turbo Speed 4.8 GHz
Number of Cores 8-core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
Processor Main Features Intel Turbo Boost Technology
CPU Socket LGA1200 Socket
Chipset Type Intel W480
