Hewlett Packard Enterprise - HPE ProLiant DL360 Gen10 Plus Network Choice

Server - rack-mountable - 1U - 2-way - 1 x Xeon Silver 4314 / 2.4 GHz - RAM 32 GB - SATA/SAS/NVMe - hot-swap 2.5" bay(s) - no HDD - 10 GigE - monitor: none

Hewlett Packard Enterprise
P55242-B21
N/A
0190017604725
N/A
New

Price: $4,409.50

Total Available: 42

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description HPE ProLiant DL360 Gen10 Plus Network Choice - rack-mountable - Xeon Silver 4314 2.4 GHz - 32 GB - no HDD
Type Server - rack-mountable
Height (Rack Units) 1U
Localization Region: Worldwide
Server Scalability 2-way
Processor 1 x Intel Xeon Silver 4314 / 2.4 GHz (3.4 GHz) (16-core)
Cache Memory 24 MB L3 cache
Cache Per Processor 24 MB
RAM 32 GB (installed) / 4 TB (max) - DDR4 SDRAM
Server Storage Bays Hot-swap 2.5"
Hard Drive No HDD
Optical Storage No optical drive
Video Memory 16 MB
Networking 10 GigE
Power Redundancy Yes
Dimensions (WxDxH) 17.1 in x 30.3 in x 1.7 in
Weight 28.75 lbs
Manufacturer Warranty Limited warranty - parts and labor - 3 years - on-site - response time: next business day
General
Type Server
Product Form Factor Rack-mountable - 1U
Embedded Security Trusted Platform Module (TPM) Security Chip
Server Scalability 2-way
Hot-Swap Bays Qty 8
Localization Region: Worldwide
Expansion / Connectivity
Bays 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots 1 (total) / 1 (free) x PCIe 4.0 x16 - full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - low-profile (x16 mode)
Interfaces 3 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 1 x HPE iLO (1 in front) (service port) ¦ 1 x USB 2.0 (1 in front) ¦ 1 x VGA ¦ 1 x HPE iLO ¦ 2 x LAN (10Gigabit Ethernet)
Manufacturer Warranty
Service & Support Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Miscellaneous
Included Accessories HPE Easy Install Rails, CPU standard heatsink, 7 x high performance fans, 31 x DIMM blanks
Compliant Standards WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, UEFI, ACPI 6.3, SMBIOS 3.2
RAM
Installed Size 32 GB / 4 TB (max)
Technology DDR4 SDRAM
Effective Memory Speed 2933 MHz
Rated Memory Speed 3200 MHz
Form Factor DIMM 288-pin
Slots 32 (total) / 31 (empty)
Features Registered, dual rank, HPE SmartMemory
Configuration Features 1 x 32 GB
Networking
Interface (Bus) Type Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports 2 x 10 Gigabit Ethernet
Ethernet Controller Broadcom BCM57416
Data Link Protocol 10 Gigabit Ethernet
Remote Management Controller Integrated Lights-Out 5
Features Wake on LAN (WoL), PXE support
Power
Device Type Power supply - hot-plug
Power Redundancy Yes
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Voltage Required AC 120/230 V
Power Provided 800 Watt
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 10 - 90% (non-condensing)
Storage Controller
Type 1
Buffer Size 4 GB
Cache Memory
Installed Size L3 cache - 24 MB
Cache Per Processor 24 MB
Optical Storage
Type No optical drive
Monitor
Monitor Type None.
Graphics Controller
Video Memory 16 MB
Video Interfaces VGA
Hard Drive
Type No HDD
Dimensions & Weight
Width 17.1 in
Depth 30.3 in
Height 1.7 in
Weight 28.75 lbs
Processor / Chipset
CPU Intel Xeon Silver 4314
Clock Speed 2.4 GHz
Max Turbo Speed 3.4 GHz
Number of Cores 16-core
CPU Qty 1
Max CPU Qty 2
CPU Upgradability Upgradable
Chipset Type Intel C621A
